EATON Arrow Hart™ Eaton Wiring Devices AH6808GDAC 1-Phase Manual Motor Control Switch, 250/600 VAC, 20 to 30 A, 2 hp, 3 hp, 5 hp, 7-1/2 hp Power Rating, DPST Contact
AH6808GDAC
MFG #: AH6808GDAC
$82.53
/ EA
Non-Stock Item
- Action: Maintained
- Amperage Rating: 20 to 30 A
- Connection: Back/Side Wired
- Contact Configuration: DPST
- Contact Rating: 20/30 A at 250/600 VAC
- Country of Origin: MX
- Dimensions: 4 in L x 4 in W x 12 in H
- Enclosure: NEMA 1
- Manufacturer Name: Eaton
- Material: Glass Filled Nylon
- Number of Poles: 2
- Power Rating: 2 hp, 3 hp, 5 hp, 7-1/2 hp
- Type: 1-Phase
- Voltage Rating: 250/600 VAC
Industrial grade manual motor controllers double-pole, 1-phase, 20/30 A side wired screw. Compact design provides extra wiring room for easy, fast installation. Easy to read electrical ratings on rugged steel mounting straps ensure accurate identification. Highly visible ''ON/OFF'' markings on large, rugged toggles make the switch easy to operate and reduce the risk of errors. Cam and roll design provides dependable, trouble-free switch action. Distinct wire pockets and THK wall arc barriers prevent strands from straying. Robust, 1-piece, moveable and stationary contact arms with large silver cadmium buttons limit heat build-up for excellent continuity and long life. Screw and clamp or box lug terminals to meet individual project requirements.
- Standards
- Application
- Item Features
CSA C22.2 No. 14|UL 508
Industrial Applications
- 14 to 10 AWG allowable wire range
- Totally enclosed body eliminates exposed contacts
- Enclosures can be padlocked to conform to OSHA lockout requirements
- Cam and roll design provides dependable, trouble-free switch action
- Separate arc quenching chambers isolate each pole
- Front terminals are designed for easy wiring
